1.4 Lac / Piece
| Business Type | Manufacturer, Exporter, Supplier, Retailer |
| Minimum Order Quantity | 1 Piece |
| Machine Type | Manual Edge Banding Machine |
| Model Name/Number | MEB-FX-02 |
| Click to view more | |
Product Details
Functions
Gluing,Trimming and end cutting
Power
3HP
Automatic Grade
Manual
Voltage
220/380/415
Phase
1Phase or 3Phase
Edge Thickness
10-50mm
Weight
180 Kgs
Edge Belt Thickness
10-50mm
Size
1250 x 800 x 1250 mm
Usage/Application
Edge banding using Gluing,double side trimming and end cutting of boards
Feeding Speed
Variable
Air Pressure
4-6Bar
Glue Pot Capacity
1-2Kgs
Frequency
50Hz
Working Pressure
4-6 Bar
Panel Thickness
10-50mm
Heating Element
3-4 Heating elemnts used for even heating
Production Capacity
5
Delivery Time
10-50 days from order
Packaging Details
Wooden Box or Plastic film
